Operating Voltage:525-690 VAC

Motor Power:100 HP

Motor Current:112 A

Maximum Frequency:400 Hz

Braking Method:DC Injection & Dynamic Braking Transistor

Dimensions (HxWxD):24.5 in x 11.4 in x 11.4 in

Net Weight:90 lbs

    The ABB ACS800-01-0100-3+D150+P901 is a highly efficient and versatile AC drive designed for modern industrial automation requirements. Its advanced vector control technology ensures precise motor speed control and enhanced energy efficiency.

    Featuring a wide operating voltage range, this drive is suitable for various industrial settings, supporting a broad spectrum of motor power requirements from 1 HP to 750 kW. The adjustable maximum frequency allows for smooth operation and optimal process control.

    Equipped with dynamic braking via DC injection, it provides effective deceleration and safety during stop operations, reducing wear and tear on the mechanical components. The drive supports Modbus RTU communication interface for seamless integration into existing control systems.

    With an IP20 protection class, the ABB ACS800-01-0100-3+D150+P901 is designed to withstand harsh industrial environments, ensuring reliable performance under challenging conditions. The compact design and low net weight (90 lbs) facilitate easy installation and maintenance.

    The ACS800 Series is part of ABB‘s commitment to delivering innovative and sustainable solutions. It comes with a comprehensive set of features and functionalities that cater to diverse industry needs, making it an ideal choice for enhancing productivity and efficiency in manufacturing, processing, and other sectors.
