Product Type:IGBT Module

Model Number:5SHX 1000H0003

Manufacturer:ABB

Dimension (WxHxD):145mm x 145mm x 70mm

Operating Temperature Range:-40°C to +125°C

Input Voltage:350V DC

Output Current:1000A

Peak Output Current:1500A

Max Gate Voltage:25V

Insulation Resistance:≥10MΩ @ 500V DC

Operating Frequency:up to 6 kHz

Cooling Method:Air Cooled

    Unmatched Performance: Designed to deliver exceptional power handling capabilities in industrial automation systems, ensuring peak efficiency and reliability under extreme conditions.

    Robust Construction: Utilizing advanced materials and manufacturing techniques, this IGBT module is built to withstand harsh industrial environments without compromising on performance.

    Advanced Cooling System: Features an efficient thermal conduction system that ensures optimal heat dissipation, preventing overheating and enhancing the longevity of the module.

    Wide Operating Range: Suitable for use across a broad temperature spectrum (-40°C to +125°C), making it ideal for applications in diverse geographical locations.

    Simplified Installation: With its standard panel mount design, the ABB 5SHX 1000H0003 IGBT module simplifies installation processes, reducing downtime and increasing productivity.
