Operating Frequency:10 MHz

Switching Speed:5 ns

Max Collector Current:1 A

Supply Voltage Range:10V to 30V

Temperature Range:-40°C to +125°C

Package Type:TO-220

Mounting Type:Panel Mount

Number of Channels:1

Control Logic:Positive or Negative Logic

Switching Voltage:15V

    The AB 1336-QOUT-SP13A Transistor Module offers superior reliability and efficiency for use in demanding industrial environments. Its compact size and robust design make it an ideal choice for space-constrained applications requiring high-speed switching performance.

    Featuring a wide operating temperature range from -40°C to +125°C, this module ensures stable operation across various industrial conditions. It supports a versatile input voltage range of DC 5V to 30V, providing flexibility in power supply options.

    With a maximum output current of 10A and a switching speed of 20ns, the module delivers fast response times and low power consumption, optimizing system performance and reducing energy waste.

    Designed for surface mount technology (SMD), the 3x3mm package facilitates easy integration into modern electronic circuits, minimizing assembly time and cost. The module is guaranteed to withstand over 1 million switching cycles, ensuring long-lasting durability and minimal maintenance requirements.

    Ideal for applications in motor control, power supplies, and signal processing, the AB 1336-QOUT-SP13A Transistor Module is engineered to meet the stringent demands of today’s industrial automation landscape, offering unparalleled reliability and performance.
