Communication Protocol:Modbus RTU

Data Transfer Rate:115,200 bps

Operating Voltage:12V DC

Power Consumption:Less than 2W

Temperature Range:-20°C to +70°C

Dimensions (WxHxD):48mm x 48mm x 30mm

Weight:Approx. 100g

    Integrating advanced technology, the ABB AB 1203-SM1 SCANport Module provides a robust solution for industrial automation networks. Its Ethernet interface ensures reliable data transmission at speeds up to 100 Mbps, making it suitable for demanding industrial environments.

    The module supports multiple protocols including MODBUS/TCP, DeviceNet, and CANopen, providing versatility and compatibility with various industrial systems. This feature enhances its utility across different applications, from manufacturing lines to process control systems.

    Efficient power management ensures low energy consumption, reducing operational costs while maintaining high performance standards. The operating temperature range from -20°C to +60°C guarantees stable operation under a wide range of environmental conditions, ensuring reliability in harsh industrial settings.

    With an IP20 enclosure rating, the module offers basic protection against dust and light splashes, safeguarding internal components against minor contaminants and spills commonly found in industrial spaces.

    Compact in size (120mm x 70mm x 20mm) and lightweight (0.3kg), the ABB AB 1203-SM1 SCANport Module is easy to install and integrate into existing systems. It adheres to international safety and quality standards, ensuring a safe and efficient operation in industrial automation applications.
