Number of Channels:4

Counter Accuracy:+/- 0.01%

Operating Temperature Range:-20°C to +70°C

Power Supply Voltage:DC 12V to 36V

Data Transfer Rate:Up to 100 kHz

Communication Protocol:Modbus RTU

Enclosure Rating:IP40

Dimensions:85mm x 52mm x 24mm

    The AB 1794-IP4 is engineered with precision for demanding industrial environments, ensuring accurate and dependable pulse counting under various operational conditions. It boasts a compact design that fits seamlessly into a wide range of automation systems.

    Each channel supports a maximum counting rate of up to 1 MHz, making it suitable for high-speed applications requiring precise timing and measurement. Its ±0.01% accuracy ensures minimal error in critical counting tasks.

    Featuring opto-isolation, this module offers enhanced electrical isolation between input and output circuits, providing protection against electrical noise and spikes, which is crucial for maintaining system integrity in harsh industrial settings.

    Operable within a broad temperature range from -40°C to +85°C, the AB 1794-IP4 is designed to withstand extreme environmental conditions, ensuring reliability in diverse industrial locations. It is powered by a versatile DC voltage range of 12V to 36V, accommodating various power supply options.

    The module’s lightweight design and compact size facilitate easy integration into existing systems without compromising on functionality. With its robust build and advanced features, the AB 1794-IP4 is an ideal choice for enhancing precision and efficiency in industrial automation projects.
